Smith-Blair offers the most complete line of service saddles in the industry
for fast, dependable tapping of all types of pipes.
Such outstanding features as the Taper SealTM gasket, heavy forged bales, and wrap-around design that reinforces and supports the pipe, are combined in superior service saddles to provide low initial cost, ease of installation, and excellent lasting qualities.
Increased protection against corrosion is available with the use of Smith-Blair Flexi-BlueTM epoxy coating or all stainless steel saddles. These products give you the option to select the degree of corrosion resistance necessary for your application.
In addition to the primary use, tapping pipe to provide branch connections, Smith-Blair Service Saddles are widely used for such special applications as installing air and vacuum valves. Pilot tubes and other equipment, and as pipe hangers and sign mounting brackets.
Smith-Blair Service Saddles are available in a wide variety of sizes, configurations and materials for use on all types of pipe, in all types of environmental conditions, to make taps ranging from a 5/8" (15mm)
| # | SADDLE | DESCRIPTION | TYPES OF PIPE | WORKING
PRESSURE |
TEMP.
RANGE |
|---|---|---|---|---|---|
| 311 |  |
Single Bale
Iron Service Saddle Pipe Sizes: 1" thru 12" Outlet Sizes: 5/8" thru 1 1/2" |
Steel, Cast Iron,
Asbestos Cement, *PVC |
300 PSI | -40°
thru +212°F |
| 313 |  |
Double Bale
Iron Service Saddle Pipe Sizes: 1 1/4" thru 18" Outlet Sizes: 5/8" thru 4" |
Steel, Cast Iron,
Asbestos Cement, *PVC |
300 PSI | -40°
thru +212°F |
| 315 |  |
Single Strap, Flexi-BlueTM Epoxy
Coated Iron Service Saddle with wide Stainless Steel Straps Pipe Sizes: 1" thru 12" Outlet Sizes:5/8" thru 2" |
Steel, Cast Iron,
Asbestos Cement, PVC |
300 PSI | -40°
thru +212°F |
| 317 |  |
Double Strap, Flexi-BlueTM Epoxy
Coated Iron Service Saddle with wide Stainless Steel Straps Pipe Sizes: 1 1/4" thru 12" Outlet Sizes:5/8" thru 2" |
Steel, Cast Iron,
Asbestos Cement, PVC |
300 PSI | -40°
thru +212°F |
| 319 |  |
Double Bale Iron
Service Saddle FM Approved for Fire Sprinkler Service |
Steel, Cast Iron | Up to
1200 PSI |
-40°
thru +212°F |
| 323 |  |
Double Bale Bronze Saddle
Pipe Sizes: 3" thru 20" Outlet Sizes: 5/8" thru 2 1/2" |
|||
| 331 |  |
Double Bale
Iron Repair Service Saddle Pipe Sizes:4" thru 12" Outlet Sizes: 5/8" thru 2" |
Steel, Cast Iron, Asbestos Cement | 300 PSI | |
| 357 |  |
Double Strap, Flexi-BlueTM Epoxy
Coated Iron Service Saddle with wide Stainless Steel Straps Pipe Sizes: 6" thru 12" Outlet Sizes: 3" and 4" |
PVC, Steel
Cast Iron |
150 PSI | |
| 362 |  |
Double Bale
Iron Service Saddle Pipe Sizes: 6" thru 36" Outlet Sizes 5/8" thru 2" |
Concrete Cylinder
Pipe, Concrete Coated Steel Pipe |
300 PSI | |
| 366 |  |
Trible Bale
Iron Service Saddles Pipe Sizes: 19.25" O.D. thru 43.15" O.D. Outlet Sizes: 3/4" thru 2" |
Large Diameter
Steel, Cast Iron, Asbestos Cement PVC |
300 PSI | |
| 371 |  |
Single Bolt All Stainless
Steel Service Saddles Pipe Sizes: 4" thru 12" Outlet Sizes: 1/2" thru 1" |
Plastic | 150 PSI | |
| 372 |  |
Double Bolt All Stainless
Steel Service Saddles Pipe Sizes: 4" thru 12" Outlet Sizes: 1 1/4" thru 2" |
Plastic | 150 PSI | |
| 391 |  |
Service Saddle
Bronze with Stainless Steel Straps Pipe Size: 2" thru 12" Outlet Sizes: 3/4" thru 2" |
PVC (Cast Iron
and Steel Sizes) |
200 PSI | |
| 393 |  |
Service Saddle
Bronze with Stainless Steel Straps Pipe Size: 2" thru 12" Outlet Sizes: 3/4" thru 2" |
PVC (Cast Iron
and Steel Sizes) |
200 PSI |
