The Flanged Coupling Adapter combines a flexible coupling with a flange
to create a compact, flexible fitting to connect plain end pipe to flanged
fittings, meters, valves or equipment. In addition to its compactness,
accomplished by eliminating the need for both a flanged spool and coupling,
Flanged Coupling Adapters provide versatility on the job site. special
length flanged spools can now be made at the job site by utilizing standard
pipe and Smithe-Blair's Flanged Coupling Adapters. There are case and steel
versions available to meet your exact requirements. Check the many benefits
and applications that are listed.
Flanged Coupling Adapters Provide:
| # | PRODUCT | DESCRIPTION | FOR PIPE
SIZES |
WORKING
PRESSURE |
TEMPERATURE | SPECIAL CHARACTERISTICS |
|---|---|---|---|---|---|---|
| 912 |  |
Ductile Iron FCA
Original Range & New OmniTM Range |
3" thru 12" | 175 PSI | 150°F
higher with special gaskets |
Compact
Ductile Iron Construction Economical |
| 913 |  |
Steel FCA | 3" & larger | 150* PSI +
according to size & design |
Fitts water & butterfly valves
Facilitates anchor assembly Available in larger & non-standard sizes Available with heavy flange or to special lengths |
|
| 914 |  |
Steel Reducing FCA | 3" & larger | 150* PSI +
according to size & design |
To reduce or increase to connect flange to
any pipe size. Available with heavy flange or to special requirements |
|
| 916 |  |
Ring-Type Ductile Iron
FCA |
3" thru 16" | 175 PSI | For machined and asbestos-cement pipe
Compact Economical |
|
| 926 |  |
Ductile Iron
Meter Coupling |
1½ & 2" | 175 PSI | To connect meter to plain-end steel,
PVC or copper pipe Compact Economical |
|
| 932 |  |
Insulating Ductile Iron
FCA |
3" thru 12" | 175 PSI | Insulates Cast Iron & Steel Pipe
Compact Economical |
|
| 933 |  |
Insulating Steel FCA | 3" & larger | 150* PSI +
according to size & design |
Insulates Cast Iron & Steel Pipe
Compact Economical |
